Rugged Industrial Handheld
C13

Highlights

NFC (ISO 14443 A/B, ISO 15693, ISO 18092)
Wi-Fi | Bluetooth | 3G/4G | GNSS
Caméra frontale 5,0 MP | Caméra arrière 13,0 MP
Certifié IP65, certifié MIL-STD-810H
Résistant aux chutes jusqu’à 1,2 m de hauteur

Spécifications



Electrical specifications
Battery3.87 V, 4000 mAh Lithium-ion Battery (removable)
Memory4 GB RAM
64 GB ROM
Input/OutputMicro USB 2.0 x 1
SIM Card x 1
TF Card x 1
POGO PIN x 1
Φ3.5mm standard earphone jack x 1
CPUARM, OCTA Core
CameraFront: 5.0 Megapixel
Rear Main:
Camera 13.0MP, Autofocus,
Display

5 Inch
IPS 16:9
720×1280
320 nits

Touch Panel5 point G+FF capacitive touch screen
Corning® Gorilla® Glass
Mechanical conditions
Dimensions157.4 x 74.6 x 24.2mm
Drop HeightWithstands drops from 1.2 meters onto
composite
Drop Height wood flooring,
while powered on.
Device ColorBlack
Environmental conditions
Operating Temperature-10 °C up to 55 °C
Storage Temperature-20 °C up to 60 °C
Humidity95% (non-condensing)
Protection ClassIP65 certified, MIL-STD-810H certified
Communication specifications
WiFiWiFi 802.11 a/b/g/n/ac (2.4G+5G)
BluetoothBT5.0
Transmission distance: 10m
3G/4GGSM B2/B3/B5/B8
WCDMA B1/B2/B5/B8
TDS B34/B39
FDD B1/B2/B3/B4/B5/B7/B8/B13/B17/
B20/28AB
TDD B38/B39/B40/B41
GNSSSupport GPS, Glonass, Beidou (G+G+B)
Supported standards | Tags
NFC 13.56 MHz
ISO 14443 A and compatibleRead/write:
MIFARE® Classic/1K/4K,
MIFARE Ultralight®/C,
MIFARE® DESFire®EV1/3,
MIFARE® Smart MX,
MIFARE® Plus S / X,
MIFARE® Pro X,
NTAG 213, 215, 216, 196, DNA

Read UID only:
all other ISO14443A RFID tags
ISO 14443 B and compatibleSRI4K,
SRIX4K,
AT88RF020,
66CL160S,
SR176
ISO 15693 and compatibleEM4135,
EM4043,
EM4x33,
EM4x35,
I-Code SLI / SLIX,
I-Code SLI-2,
M24LR16/64,
TI Tag-it HF-I,
SRF55Vxx (my-d vicinity)
ISO 18092I-Code ILT-M

Description

Le C13 est un ordinateur de poche robuste et compact conçu pour une utilisation exigeante dans la logistique d’entrepôt, les services sur le terrain, la livraison express ou le paiement mobile. Son écran de 5 pouces, sa résolution de 720 × 1280 et sa certification IP65/MIL-STD-810H le rendent idéal pour les environnements de travail difficiles.

Propulsé par un processeur octa-core, avec 4 Go de RAM et 64 Go de ROM, il fonctionne parfaitement sous Android™ 11.

Il dispose d’un appareil photo arrière de 13 MP et d’une caméra frontale de 5 MP, du WiFi, Bluetooth 5.0, 3G/4G ainsi que du GNSS (GPS, Glonass, Beidou). Le module NFC intégré prend en charge les normes ISO 14443 A/B, ISO 15693 et ISO 18092. Des accessoires en option comme des gâchettes de lecture, des stations d’accueil ou des supports pour véhicules ajoutent de la flexibilité.

Domaines d’application

  • Logistique d’entrepôt
  • Service sur le terrain
  • Livraison express
